RF Guided Missile Bag

RF Guided Missile Bag

  • The product described here can be used for guided missiles that need protection against negative influences resulting from elevated electromagnetic fields, such as Milan and TOW
  • EMC casing for guided missiles consisting of inner and outer textile layer in the form of a bag. The opening is sealed by means of velcro.
  • Inner casing material: silver-coated Nylon; Ripstop weave
  • Weight: 50 g/ m² ± 15%;
  • Material Attenuation of Shielding: approx. 60 dB between 30 MHz and 3 GHz
  • Surface Resistance: on average < 0.3 Ohm.
  • Outer Casing Material: laminated Polyamid according to TL 8305-0278-type E-1, Colour: stone grey
  • Dimensions:   Length: 1630 mm
  • Diameter: 250 mm Length of velcro band for closing the casing: 720 mm
  • The EMV protective casing can be reused, as long as the inner casing has no obvious damage, such as tears or holes
  • Discounts Available for bulk orders
  • Product can be embroidered with wording/logo if required (extra charge)
